10GBASE-SR Gigabit Ethernet SFP JUNIPER EX-SFP-10GE-SR
Liên hệ báo giá10GBASE-SR Gigabit Ethernet SFP JUNIPER EX-SFP-10GE-SR
– Small Form Factor Pluggable 10 Gigabit Ethernet (SFP+) SR Optics.
Thông số kỹ thuật
| Transceiver Type | SFP+ |
| Connector | LC |
| Monitoring Available | Yes |
| Digital Optical Monitoring | Yes |
| Digital Diagnostic Monitoring | Transceiver temperature Transceiver supply voltage TX bias current TX output power RX received optical power |
| Signaling rate, each lane | 10 Gbps |
| Transmitter fibers | Dual |
| Transmitter wavelengths (range) | 850 nm |
| Transmitter output power, each lane (minimum) | –7.3 dBm |
| Transmitter output power, each lane (maximum) | –1 dBm |
| Receiver input power, each lane (minimum) | –9.9 dBm |
| Receiver input power, each lane (maximum) | –1 dBm |
| Cable type | MMF |
| Operating Temperature (range) | 0° C to 70° C |
| Storage temperature | –40° C to 85° C |
– Bảo hành: 12 tháng.
