THÔNG TIN SẢN PHẨM
Chi tiết và thông số kỹ thuật
Device
| COMPONENT |
SPECIFICATION |
| Image Sensor |
1/2.8”, 2.0 megapixel, progressive scan, CMOS |
| Minimum Illumination |
Color: 0.001 Lux (F1.5, AGC ON) | 0 Lux with IR |
| Shutter Time |
Auto/Manual, 1 ~ 1/100000s |
| Lens |
4.5 ~ 148.5mm, AF Automatic Focusing And Motorized Zoom Lens |
| WDR |
120dB |
| Angle of View |
H: 56.2° ~ 2.6°, V: 33.5° ~ 1.4°, O: 65.4° ~ 3.0° |
| Angle Adjustment |
Pan: 360° (endless) Tilt: -15° ~ 90° (auto reverse) |
| 3-Axis Adjustment |
– |
| Day & Night |
IR-cut filter with auto switch (ICR) |
| IR Range |
Up to 150m (492 ft) IR range |
Compression Standard
| COMPONENT |
SPECIFICATION |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| Video Bit Rate |
128 Kbps~16 Mbps |
| Multi-Stream |
Yes |
| Analytics |
Motion detection, Audio detection, Tampering Alarm
Support false alarm filtering: Line crossing detection, Intrusion
detection, Region entrance detection, Region exit detection; |
| COMPONENT |
SPECIFICATION |
| Max. Image Resolution |
1920 x 1080 |
| Frame Rate |
60fps (1920 x 1080) |
| ROI Codec |
Support |
| OSD |
Up to 8 OSDs |
| Image Setting |
White Balance, Digital Noise Reduction, HLC, BLC, Defog |
Network
| COMPONENT |
SPECIFICATION |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP,
UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
Interface
| COMPONENT |
SPECIFICATION |
| Communication Interface |
1 * RJ45 10M/100M Base-TX Ethernet |
| Local Storage |
Micro SD, up to 256GB |
| Audio Compression |
G.711U,G.711A |
| Built-in Mic |
– |
General
| COMPONENT |
SPECIFICATION |
| Operating Conditions |
Temperature: -40°C ~65°C (-40°F ~ 149°F),
Humidity: ≤95% RH |
| Power Consumption |
Max 48W |
| Power Supply |
AC 24V±25%, DC 24V±25%, PoE (PSE Required) |
| Weather Proof Rating |
IP66 |
| Vandal Resistant |
– |
| Dimensions |
Ø227 x 359.4mm (Ø8.9” x 14.2”) |
| Weight |
5.3kg (11.68lb) |
| Software: |
Includes Video Insight VMS License |
| Warranty |
4 Year Advanced Replacement |
