THÔNG TIN SẢN PHẨM
Chi tiết và thông số kỹ thuật
Device
| COMPONENT |
SPECIFICATION |
| Image Sensor |
1 / 2.8″, 4MP Progressive Scan CMOS |
| Min Illumination |
Color: 0.003Lux (F1.5, AGC ON) | 0Lux with IR |
| Shutter Time |
Auto/Manual, 1 ~ 1/100000s |
| Lens |
4.8mm to 120mm AF automatic focusing and motorized zoom lens |
| True WDR |
120 dB |
| Angle of View |
H: 52.20°~2.74°, V: 30.81°~1.54°, O: 64.20°~3.23° |
| Angle Adjustment |
360° (endless), –15° ~ 90° (auto reverse) |
| Digital Zoom |
16x |
| Optical Zoom |
25x |
| Day & Night |
IR-Cut Filter with Auto Switch (ICR) |
| IR Range |
Up to 100m (328ft) IR range |
Compression Standard
| COMPONENT |
SPECIFICATION |
| Video Compression |
H.265, H.264, MJPEG |
| Video Bit Rate |
128 Kbps~16 Mbps |
| Tri-Stream |
Yes |
| Analytics |
Motion Detection, Motion detection, Audio detection, Tampering
Alarm, Line crossing detection, Intrusion Detection, Enter Area,
Leave Area Detection |
| COMPONENT |
SPECIFICATION |
| Max. Image Resolution |
2688*1520 |
| Frame Rate |
30fps (2688*1520) |
| ROI Codec |
Support |
| Image Setting |
White Balance, Digital Noise Reduction, Smart IR, HLC, BLC, Defog |
Network
| COMPONENT |
SPECIFICATION |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP,
HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS |
Interface
| COMPONENT |
SPECIFICATION |
| Communication Interface |
10M/100M Base-TX Ethernet |
| Local Storage |
Micro SD card up to 256 GB |
| Audio Compression |
G.711U,G.711A |
| Audio I/O |
1/1 |
| Alarm I/O |
2/1 |
General
| COMPONENT |
SPECIFICATION |
| Safety |
CE, IEC62368-1 |
| EMC |
FCC Part 15, EN 55032:2015+A11:2020, EN 55035: 2017+A11:2020 |
| Operating Conditions |
Temperature: -40°C~70°C(-40°F~158°F),
Humidity:≤95%RH(Non-Condensing) |
| Power Consumption |
Max 21.0 W |
| Power Supply |
DC 12V±25% 3A, PoE+ (IEEE 802.3af) |
| Weather Proof Rating |
IP67 |
| Vandal Resistant |
IK10 |
| Dimensions |
Ø166 x 295mm (Ø6.5” x 11.6”) |
| Net Weight |
3.05kg (6.72lb) |
| Software |
No license required for use with Video Insight Software |
