Device
| COMPONENT | SPECIFICATION |
|---|---|
| Image Sensor | 1/2.7”, 8.0 megapixel, progressive scan, CMOS |
| Min Illumination | Color: 0.01Lux (F2.0, AGC ON) | 0Lux with IR on |
| Shutter Time | Auto/Manual, 1 ~ 1/100000s |
| Lens | 4.0mm@F2.0 |
| WDR | 120dB |
| Angle of View | H: 86.5°, V: 44.1°, O: 112.5° |
| Angle Adjustment | Pan: 0° ~ 360° | Tilt: 0° ~ 90° | Rotate: 0° ~ 360° |
| 3-Axis Adjustment | Yes |
| Day & Night | IR-cut filter with auto switch (ICR) |
| IR Range | Up to 30m (98 ft) IR range |
Compression Standard
| COMPONENT | SPECIFICATION |
|---|---|
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Video Bit Rate | 128 Kbps~16 Mbps |
| Tri-Stream | Yes |
| Analytics | Cross Line, Intrusion, Enter Area, Leave Area Detection. Motion Detection, Tampering Alarm, Audio Detection. |
| COMPONENT | SPECIFICATION |
|---|---|
| Max. Image Resolution | 3840 x 2160 |
| Frame Rate | 20fps (3840 x 2160) |
| ROI Codec | Up to 8 Areas |
| Image Setting | White Balance, Digital Noise Reduction, Smart IR, Flip, Dewarping, HLC, BLC |
Network
| COMPONENT | SPECIFICATION |
|---|---|
| Alarm Light | Supported |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, SNMP, HTTPS, SMTP, SSL |
Interface
| COMPONENT | SPECIFICATION |
|---|---|
| Communication Interface | 1 RJ45 10M/100M Base-TX Ethernet |
| Local Storage | Micro SD, up to 256GB |
| Built-in Mic | Supported |
| Built-in Speaker | Supported |
General
| COMPONENT | SPECIFICATION |
|---|---|
| Operating Conditions | Temperature: -30°C ~ 60°C (-22°F ~ 140°F) Humidity: ≤95% RH (non-condensing) |
| Power Consumption | Max 10.5W |
| Power Supply | DC 12V±25%, PoE (IEEE 802.3af) |
| Weather Proof Rating | IP67 |
| Vandal Resistant | – |
| Dimensions | 91 × 75 × 74mm (7.5” × 3.0” × 2.9”) |
| Weight | 0.41kg (0.90lb) |
| Software | Includes Video Insight VMS License |
| Warranty | 4 Year Advanced Replacement |
