THÔNG TIN SẢN PHẨM
Chi tiết và thông số kỹ thuật
- 8× 10/100/1000 Mbps RJ45 ports
- 8× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE power up to 30 W for each PoE port
- Supports PoE power up to 65 W for all PoE ports*
- Up to 250m (820ft) data and power transmitting range under Extend Mode**
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required.†
| HARDWARE FEATURES |
| Interface |
• 8× 10/100/1000 Mbps RJ45 Ports• AUTO Negotiation• AUTO MDI/MDIX |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity |
Fanless |
| Physical Security Lock |
Yes |
| External Power Supply |
External Power Adapter(Output: 53.5VDC / 1.31A) |
| Packet Forwarding Rate |
11.904 Mpps |
| PoE Ports (RJ45) |
• Standard: 802.3 af/at compliant• PoE Ports: Ports 1–8• Power Supply: 65 W |
| Mac Address Table |
4K |
| Jumbo Frame |
16 KB |
| Switching Capacity |
16 Gbps |
| Dimensions ( W x D x H ) |
6.2×4.0×1.0 in (158×101×25 mm) |
| Max Power Consumption |
• 4.7 W (220/50 Hz no PD connected)• 74.39 W (220/50 Hz with 64 W PD connected) |
| Max Heat Dissipation |
• 16.03 BTU/h (no PD connected)• 253.67 BTU/h (with 64 W PD connected) |
| SOFTWARE FEATURES |
| Transmission Method |
Store-And-Forward |
| Advanced Functions |
• Compatible With IEEE 802.3af/at Compliant PDs• IGMP Snooping• Mac Address Auto-Learning And Auto-Aging• IEEE802.3x Flow Control• 802.1p/DSCP QoS• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-8) |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
• DS108GP• Power Adapter• Installation Guide |
| Environment |
• Operating Temperature: 0–40 ℃ (32–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing |
