Dimensions (excluding antenna connectors and mounting accessories)

39×160×86 mm (H x W x D)

Fixed port

UpLink：10/100/1000M×1，RJ-45
LAN：10/100/1000M×4，RJ-45

PoE

802.3af

Local power supply

54V DC

Console port

1

USB port

1

Built-in antenna

Internal Omni-directional antenna

3dBi antenna gain @2.4GHz

4dBi antenna gain @5GHz

Working frequencies

802.11ax/ac/n/a: 5.725 GHz – 5.850 GHz; 5.47 GHz – 5.725 GHz; 5.15 GHz – 5.35 GHz

802.11ax/b/g/n: 2.4 GHz – 2.483 GHz

Modulation technology

OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps

DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps

MIMO-OFDM(11n): MCS 0-15

MIMO-OFDM(11ac): MCS 0-9

MIMO-OFDM(11ax): MCS 0-11

Modulation mode

11b: DSS:CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps

11a/g: OFDM:64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps

11n: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM

11ac/ac wave2: MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM, 256QAM

11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM

Transmit power (combined power)

20 dBm (Varies depending on local laws and regulations)

Adjustable power granularity

1 dBm

Power consumption

≤15W (include USB)

Reset/restoration to factory default

Supported

Operating temperature/storage temperature

-10ºC to +55ºC/-40ºC to +70ºC

Operating humidity/storage humidity

5% – 95% (non-condensing)

Safety compliance

GB 4943, EN/IEC/UL 60950-1, EN/IEC/UL 62368-1

EMC

EN 55024, EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 60601-1-2, EN 301 489-1, EN 301 489-17

Environment

GB/T 2423, GB/T 13543, GB 4208

Radio frequency certification

FCC Part 15, EN 300 328, EN 301 893, and MIIT SRRC

MTBF

2230121H
