• 2.8 mmDetect: 85 m (278 ft)Observe: 35 m (116 ft)Recognize: 17 m (56 ft)Identify: 8 m (28 ft)• 4 mmDetect: 107 m (350 ft)Observe: 44 m (146 ft)Recognize: 21 m (70 ft)Identify: 11 m (35 ft)
Điều chỉnh góc (Thủ công)
Vùng
Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Đèn chiếu sáng
Đèn hồng ngoại IR
Quantity: 4Range: 30mWavelength: 850nm
Đèn LED trắng
Quantity: 4Range: 30m
Điều khiển bật/tắt đèn chiếu sáng
Auto/Scheduled/Always on/Always off
VIDEO
Độ phân giải tối đa
3840 X 2160
Luồng chính
• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps• Resolution:3840×2160, 2560×1440, 2304×1296, 2048×1280, 1920×1080,1280×720• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.If 120dB is turned on, the frame rate can only support up to 20fps.
Luồng phụ
• Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps• Resolution:848×480, 704×576, 640×480, 640×360, 352×288, 320×240• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.If 120dB is turned on, the frame rate can only support up to 20fps.
Kiểm soát Bit Rate
CBR, VBR
Nén video
Main Stream: H.265+/H.265/H.264+/H.264Sub-Stream: H.265/H.264
Loại H.264
High Profile
H.264+
Main Stream Supported
Loại H.265
Main Profile
H.265+
Main Stream Supported
Video Bit Rate
Main Stream: 256 Kbps to 8 MbpsSub-Stream: 64 Kbps to 512 Kbps
Hình ảnh
Cài đặt hình ảnh
• Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance• Prevent Overexposure to Infrared Light• HLC Adjustable by Client Software
Tăng cường hình ảnh
BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range
120 dBNote: When People & Vehicle Analytics is enabled, only DWDR is supported.
