THÔNG TIN SẢN PHẨM
Chi tiết và thông số kỹ thuật
Thông số sản phẩm
| Bảo hành | 36 tháng |
| Ram hỗ trợ | 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory Dual channel memory architecture Support for DDR4 2666/2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Kiểu Sockets Supported | LGA1151 |
| Chipset | Intel® H310 Express Chipset |
| khe cắm mở rộng | 1 x PCI Express x16 slot, running at x16 (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 2.0 standard.) |
| LAN – WiF | Realtek® GbE LAN chip (10/100/1000 Mbit) |
| Âm thanh | Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel |
| Operating System Support | Support for Windows 10 64-bit |
| Cổng I / O phía sau | 1 x PS/2 keyboard/mouse port 1 x parallel port 1 x serial port 1 x D-Sub port 2 x USB 3.1 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Cổng I/O ở trong | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x USB 3.1 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) 1 x Clear CMOS jumper |
| Chuẩn thiết kế ATX | Micro ATX Form Factor; 22.6cm x 17.4cm |
| Cổng lưu trữ / kết nối | 4 x SATA 6Gb/s connectors |
| Đồ họa | 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz |
