Mô tả
Thông số sản phẩm
| Bảo hành | 36 tháng |
| Ram hỗ trợ | 2 x DDR4 DIMM DDR4 2933/2666/2400/2133 MHz max 64gb |
| Kiểu Sockets Supported | Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron |
| Chipset | Intel® H410 Express Chipset |
| khe cắm mở rộng | 1 x PCI Express x16 slot, running at x16 2 x PCI Express x1 slot |
| LAN – WiF | Realtek® GbE LAN chip (1000/100 Mbit) |
| Âm thanh | Realtek® ALC887 codec |
| Operating System Support | Support for Windows 10 64-bit |
| Cổng I / O phía sau | 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Cổng I/O ở trong | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x RGB LED strip header 4 x SATA 6Gb/s connectors 1 x M.2 Socket 3 connector 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x serial port header 1 x Clear CMOS jumper |
| Chuẩn thiết kế ATX | Micro ATX Form Factor; 22.6cm x 18.5cm |
| Cổng lưu trữ / kết nối | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support) 4 x SATA 6Gb/s connectors 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
| Đồ họa | 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz |
