THÔNG TIN SẢN PHẨM
Chi tiết và thông số kỹ thuật
Thông số sản phẩm
| Bảo hành | 36 tháng |
| Ram hỗ trợ | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture |
| Kiểu Sockets Supported | Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron |
| Chipset | Intel® H470 Express Chipset |
| khe cắm mở rộng | 1 x PCI Express x16 slot, running at x16 |
| LAN – WiF | 1 x Intel® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) (LAN2) 1 x Intel® GbE LAN chip (1 Gbit/100 Mbit) (LAN1) WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band BLUETOOTH 5.1 |
| Âm thanh | Realtek® ALC1220-VB codec High Definition Audio 2/4/5.1/7.1-channel |
| Operating System Support | Support for Windows 10 64-bit |
| Cổng I / O phía sau | 1 x DisplayPortv 2 x HDMI ports 1 x USB Type-C™ port, with USB 3.2 Gen 1 support 4 x USB 3.2 Gen 1 ports 2 x RJ-45 ports 2 x SMA antenna connectors (2T2R) 3 x audio jacks |
| Cổng I/O ở trong | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 4 x SATA 6Gb/s connectors 2 x M.2 Socket 3 connectors 1 x front panel header 1 x front panel audio header 1 x speaker header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)v 1 x Clear CMOS jumper 1 x chassis intrusion header 1 x Q-Flash Plus button |
| Chuẩn thiết kế ATX | Mini-ITX Form Factor; 17.0cm x 17.0cm |
| Cổng lưu trữ / kết nối | 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x4/x2 SSD support) (M2P_SB) 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type 2260/2280 PCIe x4/x2 SSD support) (M2Q_SB) 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 Intel® Optane™ Memory Ready M.2 connectors support up to ASPM L1.2 PCIe power management protocols. |
| Chuẩn RAM | supporting up to 128GB (32 GB single DIMM capacity) |
| Đồ họa | 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz |
