Mô tả
Thông số sản phẩm
| Bảo hành | 36 tháng |
| Kích thước | ATX Form Factor; 30.5cm x 24.4cm |
| Ram hỗ trợ | 8 x DDR4 DIMM sockets Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules |
| Kiểu Sockets Supported | Support 3rd Generation AMD Ryzen™ Threadripper™ processors |
| Chipset | AMD TRX40 |
| khe cắm mở rộng | 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2) 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2) 1 x PCI Express x1 slot |
| LAN – WiF | 1 x Aquantia 5GbE LAN chip (5 Gbit/2.5 Gbit/1 Gbit/100 Mbit) (5GLAN) 1 x Intel® GbE LAN chip (10/100/1000 Mbit) (LAN) 1 x Intel® Wi-Fi 6 AX200 (Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band – BLUETOOTH 5.0) |
| Âm thanh | 1 x Realtek® ALC4050H codec+1 x Realtek® ALC1220-VB codec (Rear audio) 1 x Realtek® ALC4050H codec+1 x ESS SABRE9218 DAC chips (Front audio) Support for DTS:X® Ultra High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Operating System Support | Support for Windows 10 64-bit |
| Cổng I / O phía sau | 1 x Q-Flash Plus button 1 x Clear CMOS button 2 x SMA antenna connectors (2T2R) 1 x USB Type-C™ port, with USB 3.1 Gen 2 support 5 x USB 3.2 Gen 2 Type-A ports (red) 2 x USB 2.0/1.1 ports 2 x RJ-45 ports 1 x optical S/PDIF Out connector 5 x audio jacks |
| Cổng I/O ở trong | 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x water cooling CPU fan header 2 x system fan headers 4 x system fan/water cooling pump headers 2 x addressable LED strip headers 2 x RGB LED strip headers 3 x M.2 Socket 3 connectors 8 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C™ port, with USB 3.2 Gen 2 support 2 x USB 3.2 Gen 1 headers 2 x USB 2.0/1.1 headers 1 x noise detection header 1 x GIGABYTE add-in card connector 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) 1 x power button 1 x reset button 2 x BIOS switches 2 x temperature sensor headers 1 x Clear CMOS jumper Voltage Measurement Points |
| Chuẩn thiết kế ATX | E-ATX Form Factor; 30.5cm x 26.9cm |
| Cổng lưu trữ / kết nối | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M) 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q) 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2P) 8 x SATA 6Gb/s connectors 4 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header 4 x USB 3.2 Gen 1 ports available through the internal USB headers 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
| Chuẩn RAM | supporting up to 256 GB (32 GB single DIMM capacity) of system memory |
| Đồ họa | Support for NVIDIA® Quad-GPU SLI™ and 3-Way/2-Way NVIDIA® SLI™ technologies Support for AMD Quad-GPU CrossFire™ and 3-Way/2-Way AMD CrossFire™ technologies |
