Mô tả
Thông số sản phẩm
| Bảo hành | 36 tháng |
| Ram hỗ trợ | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture |
| Kiểu Sockets Supported | Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron thế hệ 10th vs 11th |
| Chipset | Intel® Z590 Express Chipset |
| khe cắm mở rộng | 1 x PCI Express x16 slot, running at x4 1 x PCI Express x16 slot, running at x16 (PCIEX16) 1 x PCI Express x1 slot (PCIEX4_1/PCIEX4_2.) |
| LAN – WiF | Realtek®2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate BLUETOOTH 5.1 |
| Âm thanh | Realtek® ALC4080 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
| Operating System Support | Support for Windows 10 64-bit |
| Cổng I / O phía sau | 1 x DisplayPort In Port 2 x Thunderbolt™ 4 connectors (USB Type-C® port, with USB 3.2 Gen 2 support) 2 x USB 3.2 Gen 2 Type-A ports (red) 4 x USB 3.2 Gen 1 ports 1 x Q-Flash Plus button 1 x RJ-45 port 2 x SMA antenna connectors (2T2R) 2 x audio jacks |
| Cổng I/O ở trong | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x S/PDIF Out header 2 x Thunderbolt™ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x Clear CMOS jumper 1 x Q-Flash Plus button |
| Chuẩn thiết kế ATX | Mini-ITX Form Factor; 17.0cm x 17.0cm |
| Cổng lưu trữ / kết nối | 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 3.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors |
| Chuẩn RAM | supporting up to 64GB |
| Đồ họa | 1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz |
