Mô tả
Thông số sản phẩm
| Bảo hành | 36 tháng |
| Kiểu Sockets Supported | Intel® 9th / 8th Gen Intel® Core™ i9 / i7 / i5 / i3 / Pentium® / Celeron® in the LGA1151 package |
| Chipset | Intel® Z490 Express Chipset |
| khe cắm mở rộng | 1 x PCI Express x16 slot, running at x16 (PCIEX16) 1 x PCI Express x16 slot, running at x4 (PCIEX4) 2 x PCI Express x1 slots |
| LAN – WiF | Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) |
| Âm thanh | Realtek® ALC1200 codec High Definition Audio 2/4/5.1/7.1-channel |
| Operating System Support | Support for Windows 10 64-bit |
| Cổng I / O phía sau | 2 x USB 3.2 Gen 2 Type-A ports (red) 4 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x HDMI port 1 x RJ-45 port 1 x optical S/PDIF Out connector 5 x audio jacks |
| Cổng I/O ở trong | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 2 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x USB Type-C™ port, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers |
| Chuẩn thiết kế ATX | ATX Form Factor; 30.5cm x 24.4cm |
| Cổng lưu trữ / kết nối | 2 x M.2 connectors (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2M_SB/M2A_SB) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
| Chuẩn RAM | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture |
| Đồ họa | 1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz |
